至尚科技的三軸自動劃膠機,有幾個優勢:
1.主要是對卡盒,坑盒,大尺寸皮殼,EVA,海綿等進行涂膠;
2.一次性可以放10-15CM高度的產品,劃一個取一個,劃膠頭自動下降高度;
3.劃膠范圍可以做到800*600mm,大尺寸產品可以很好實現涂膠;
4.左右沒有立柱擋住操作員取放產品,可以很方便取放產品;
5.全伺服電機帶動,穩定性好,劃膠精密度高,速度快;
有需要的可以隨時咨詢試機.
東莞市九州供應鏈管理有限公司歡迎您的蒞臨!

2023-07-19 10:15:47東莞市九州供應鏈管理有限公司

〖產品名稱〗	productname	三軸自動劃膠機 Three axis automatic gluing machine
〖型號〗	Type	ZL-S088D
〖功率〗	power	1200W
〖電壓〗	Voltage	220V
〖外觀尺寸〗	physicaldimension	長1200寬1100高1600MM Length1200width1100height1600mm
〖工作尺寸〗	Working size	長800* 寬600高150MM Length800width600*height150mm
〖工作速度〗	Working speed	S/0.35M（10-30PCS ）
〖操作黏度〗	Operatingviscosity	1-10000CPS
〖重量〗	Weight	145KG
〖適用膠水〗	Applicableglue	萬能膠，白乳膠（可以加裝熱熔膠） All purposeadhesive,white latex (hotmeltadhesive can be added)
〖劃膠閥功能〗	Gunvalvefunction	平面劃膠、平面噴膠 Planegluedrawingandplanegluespraying
〖出膠量〗	Amountofglue	2MM--10MM
〖膠桶壓力〗	Bucketpressure	0.1-0.6Pa
〖劃膠閥壓力〗	Gun valvepressure	0.4-0.6Pa
〖膠桶容積〗	Barrelvolume	6L（根據客戶需要可以選配，加大桶) 6L (optional according to customers' needs,with large barrels added)
〖系統驅動〗	Systemdrive	輸出PLC操控系統+至尚四軸操控系統V8版 OutputPLCcontrolsystem+Zhishangfour axis control system V8 version
〖伺服〗	Servos	伺服馬達 Servomotor
〖模組〗	Module	東莞市邁捷50型高精密模組 Dongguanmaijie50highprecisionmodule
〖導軌〗	Guiderail	中國臺灣尚銀精工導軌 Taiwan ,China Shangyin Seiko guide rail
〖電源〗	Powersupply	明緯電源48V，雙電源 Mingwei powersupply48V,dualpower supply
〖開關〗	Control switch	原廠家正泰與歐姆龍開關 OriginalmanufacturerChintandOMRONswitch
〖拖鏈線〗	Towline	訊馳高柔拖鏈線，耐折100萬次 Xunchi high flexible drag chain line with folding resistance of 1 million times
〖劃膠閥配置〗	HotMelt System	至尚公司劃膠閥 SpecialgunvalveofZhishangcompany
〖設備結構〗	Equipmentstructure	至尚公司設計，專利申請，焊接，龍門銑Zhishang company design, patent application, welding, gantry milling

設備優勢 Epuipment advantages

1. 此設備多用途，可以噴膠，可以劃膠。生產過程中只要換個頭即可。

Thisequipment is multi-purpose and can spray or scratch glue. Just change the head in the production process.

2.三軸機器，只能平面劃膠，平面噴膠，劃白乳膠，萬能膠等膠水。

Threeaxis machine can only draw glue on the plane, spray glue on the plane, draw white latex, universal glue and other

3.適用于皮盒，紙盒，木盒，奢侈品盒，劃膠均勻。

Itis applicable to leather boxes, cartons, wooden boxes and high-grade luxury boxes, and the glue is evenly scratched.

4.此設備機架結實，采用高速伺服馬達，針對比較高的產品，機臺底坐重，穩定，

速度快。

Theequipmentframe is solid and adopts high-speed servo motor. For higher products, the machine bottom is heavy, stableandfast.

5.適用大尺寸皮殼，內盒，內托，劃膠面積大，拿取方便，節省人員，降低員工熟練程度，提高效率。

Itis suitable for large-size leather shell, inner box and inner bracket. It has large rubber cutting area, easy to take, saves personnel,reduces staff proficiency and improves efficiency.
